The contacts do not close in accordance with the should-be position of the encoder. The problem is, when I test it, it does nothing.
I may be wrong but through very limited research (due to lack of information in the net), I wired the encoder to the PLC like this ( NOTE 1: Supply Voltage = 24VDC) ( NOTE 2: FX3U and the encoder are connected in parallel to a power source through DC+/DC-): Firstly, I need to test out the positions of the tool turret. The thing is, I was told to control the turret using a PLC (FX3U clone to be exact). Along with this is the Baruffaldi Tool Turret - TOE100.
We have a very old CNC that hasn't been used in like 20 or more years and since I just graduated, I was tasked to retrofit it. I'm new so I hope I did post this thread to the right category.
